Compatible with 90% brands inverter in the market.
Smart BMS system to optimize the performance.
Reliable LiFePO4 cell, design life 15 years, over 6000 cycles life.
Up to 15 units in parallel connection, low voltage standard, suitable for stock.
Compatible with 90% brands inverter in the market.
Smart BMS system to optimize the performance.
Reliable LiFePO4 cell, design life 15 years, over 6000 cycles life.
Up to 15 units in parallel connection, low voltage standard, suitable for stock.
| Model | WV51100L |
| Battery Module Type | LiFePO4 |
| Nominal Battery Energy(KWH) | 5.12 |
| Nominal Capacity (AH) | 100 |
| Nominal Voltage(V) | 51.2 |
| Usable Energy(KWH) | 4.096 |
| Operating Voltage(V) | 44.8~57.6 |
| Recommended Charge &Discharge C Rate | 0.5C |
| Recommended Charge/Discharge Current (A) | 50 |
| Max Charge/Discharge Current(A) | 100 |
| Dimensions(W*D*H,mm) | 482*500*133 |
| Net Weight (kg) | 45 |
| Communication | RS485/RS232/CAN |
| Working Temperature | 0C~50C Charge-10C~50C Discharge |
| Shelf Temperature | -20C~60℃ |
| Protection Level | IP20 |
| Expansion | Up to 15 units in parallel |
| Certification | CE/IEC/UL/UN38.3/MSDS |
| Design Life | 10 years+ |
| Cycle Life | >6000 |
| Warranty | 10 years |
| Compatible Inverters | SMA/Victron/Megarevo/Delios/Goodwe/Solis/Deye/SAJ/Voltronic/SRNE etc. |
